HSDJETS S-EDF 120mm HT-33 Yellow ribbon Colors PNP 12S

Fly the "Shooting Star"! Large and graceful flight characteristics. Deserving of the nickname... This bird will thrill the spectators!

4 review(s) | Add your review

Manufacturer: HSDJETS

Availability: Out of stock

SKU: A52 02 02 04J

$1,399.90

Overview
Specifications
Videos
Parts
Reviews
Q&A
Manuals
Images

SPECIFICATIONS:

Wingspan	2018 mm (79.4 in)
Length	1800 mm (70.9 in)
Flying Weight	7.5kg (16.5 lb)
Cruising speed	150～180 km/h
Flying time	3～5 mins
Wing area	56.5 dm²
Wing load	132.8 g/dm²
Main material	35 times EPO
Painting surface	Matte environmental water-borne paint + decal
Suitable experience level	□Zero basis □Beginner ■Intermediate □Advanced
PNP Assembly difficulty	□☆10mins ■★☆30mins □★★60mins
Suitable for ambient temperature	0℃～40℃
Radio System	7 channel (required & not included)
Control System	MFC-2085
Power System	120mm S-EDFwith Hobbywing 5268 Inner rotor motor
ESC	Hobbywing 160A
Servos	7.4V 25g×2 Metal gear with 480mm lead (left & right ailerons forward) 7.4V 25g×2 Metal gear with 230mm lead (Flap×2 forward) 7.4V 25g×3 Metal gear with 80mm lead (elevator×2 & rudder×1 forward) 7.4V 12g×1 Metal gear with 380mm lead with protection function (Nose wheel steering forward) 7.4V 12g×1 Metal gear with 320mm lead with protection function (Front wheel cover plate forward) 7.4V 12g×2 Metal gear with 80mm lead with protection function (Rear wheel cover plate forward)
Recommended Power Battery	6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug(required & not included)
Recommended Receiver Battery	2S,7.4V,2200～32000mAh×2,LiPo with XT60 type plug(required & not included)
Ailerons	Yes
Flaps	Yes
Elevator(Horizontal tail)	Yes
Rudder(Vertical tail)	Yes
LED lights system	Yes
Electromagnetic brake system	Yes
Reinforced gyro	Selective configuration (not included)
Packaging / Size	Packing Box + Outer Box(Card mark)/52.56×21.3×16.9(inch)
CG (Center of Gravity)	180mm from the leading edge of the Main Wing
Landing Gears	Metal electric retractable hydraulic landing gear×3
Battery Charger	LiPo battery charger (required & not included)

PACKAGE INCLUDES:

Fuselage×1 pcs
Left main wing×1 pcs
Right main wing×1 pcs
Left Horizontal tail ×1 pcs
Right Horizontal tail×1 pcs
Vertical tail×1 pcs
Nose×1 pcs
Cockpit×1 pcs
Left auxiliary tank×1 pcs
Right auxiliary tank×1 pcs
1# Main wing carbon tube L=820mm external diameter 16mm×1 pcs
2# Main wing carbon tube L=760mm external diameter 10mm×1 pcs
Horizontal Stabilizer carbon tube L=650mm external diameter 6mm×1 pcs
Accessories Bag 1 ×1 pcs
- Screw (HM3×10mm)×8 pcs (Horizontal tail)
- Screw (HA3×10mm)×8 pcs (Vertical tail / Tail nozzle)
- Screw (HA3×14mm)×8 pcs (Power)
- Screw (HM3×14mm)×8 pcs (Wing)
- Screw (HM4×25mm)×8 pcs (Auxiliary tank)
- Screw (PWM6×70mm)×6 pcs (Nose)
Accessories Bag 2 ×1 pcs
- 100mm signal line(JR male+JR male) ×8 pcs
Manual×1 pcs

REQUIRES:

7 channel radio system(radio & receiver) (required & not included)
6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug (required & not included)
2S,7.4V,2200～3200mAh×2,LiPo with XT60 type plug (required & not included)
LiPo battery charger (required & not included)

Product reviews for HSDJETS S-EDF 120mm HT-33 Yellow ribbon Colors PNP 12S

Existing reviews

Excellent quality PNP kit

I received my PNP kit a few days ago and I've been very impressed by the quality of the kit. The fit and level of completion is unmatched by anything I've ever purchased. I think the instruction manual could use a little help and battery connections are a problem if you don't have the right battery adapters. I don't understand why there are no pilots in any of the planes. What's up with that? Anyway...great plane and well worth the price!

From: Peter | Date: 7/18/2020 4:24 AM

Was this review helpful? Yes No (4/0)

What a Sweetheart!

This is the biggest foam EDF jet I have seen. However, it flies so predictably I would recommend it to an intermediate pilot. The quality of the kit is incredible and the 120mm EDF is a perfect fit for the large air frame. I did have some small issues with the landing gear but after strengthening the retract seats with a small plywood board it all works perfectly.

From: Paul | Date: 8/3/2020 4:19 AM

Was this review helpful? Yes No (5/0)

T33

First thing I can say about the T33 is that the price is definitely worth it . This is a very predictable and very easy EDF to fly a lot easier than most of the 90 mm edf. With this being said there were a few small issues one the decals that I got on my plane we're very poor quality and falling off and flaking wich is a bummer but ok it happens. I did talk with hsd and wasn't problem to replace so cool. Then the retrac needed support with a thin plywood peice like the other review person had stated. I did the same thing and it alleviated the problem I had with the foam in the inserts but only on one wing. The other one seems just fine. I think support is necessary in that area being that using the brakes can put some stress on that so other than that great edf. I have now 14 flights on this EDF that's why I decided to leave the review after I flown it a while.Im using turnigy bolt hv lipos 5400mah 65-120c and get 4min flights comfortably. Can't wait for the next new big EDF they come out with.

From: Randall | Date: 9/28/2020 2:52 AM

Was this review helpful? Yes No (2/0)

T-33 S-EDF 12S

Overall good quality airplane with good ESC and motor. There is also some room for improvement. Especially the strength of the main gear compartment and nose gear itself, The velcro strap in the battery compartment is positioned for one battery while you need two, The quality of the decals is bad, A bit more information in the manual about setting up the brakes etc. would be nice. Still waiting on an answer from customer service...

From: Stan | Date: 10/18/2020 4:39 PM

Was this review helpful? Yes No (2/0)

Write your own review

Only registered users can write reviews
Product can be reviewed only after purchasing it

Review title: *

Review text: *

Rating:

Bad
Excellent

HSDJETS-S-EDF-120mm-HT-33-PNP-12S-Assembly-and-Debugging-Guide.pdf

Q: What does KIT means?
A:It means aircraft comes without any electronic equipments, such as motor,ESC,servos,remote control,battery,etc. Clients have to buy these equipments themselves.

Q: What does KIT+L means?
A:It's a KIT version but comes with landing gear installed.

Q: What does PNP means?
A: It means the aircraft got equipments already installed and tested, but clients have to buy remote control,receiver,battery and the charger themselves. For example:servos,ESC,power system,landing gear,control system(UBEC included but no power supply), light cables(according to the model of aircrafts).It's a 90% installation.

Q: What does PNP+T means?
A: It's a PNP version with engine(general means turbine) installed and tested. It's a 95% installation.

Q: What does RTF means?
A: It means the aircraft comes with completely equipment installation(including battery supply,charger,remote control and receiver). It's a 100% installation.
