Sorry - this product is no longer available

HSDJETS S-EDF 120mm HL-39 BNHSDJETS Colors KIT, FALL SALE!!!

On Sale Now!!!

Be the first to review this product

Manufacturer: HSDJETS

Availability: Out of stock

SKU: A65 02 03 00

Old price: $699.90

Price: $549.90

Overview
Specifications
Videos
Parts
Reviews
Q&A
Manuals
Images

SPECIFICATIONS:

Wingspan	1665 mm (65.6 in)
Length	1916 mm (75.4 in)
Flying Weight	------
Flying time	------
Wing area	53.6 dm²
Wing load	------
Main material	35 times EPO
Painting surface	Matte environmental water-borne paint + decal
Suitable experience level	□Zero basis □Beginner ■Intermediate □Advanced
PNP Assembly difficulty	□☆10mins ■★☆30mins □★★60mins
Suitable for ambient temperature	0℃～40℃
Radio System	8 channel (required & not included)
Control System	MFC-2085 (required & not included)
Motor	5268-KV640(Outrunner) (required & not included)
EDF	S-EDF 120mm-10 blade (required & not included)
ESC	Hobbywing 160A brushless (required & not included)
Servos (required & not included)	25g×2 Metal gear with 80mm lead (Left & Right ailerons forward) 25g×2 Metal gear with 80mm lead (Left & Right flap forward) 25g×1 Metal gear with 80mm lead (Vertical tail forward) 25g×2 Metal gear with 80mm lead (Left & Right Elevator forward) 7.4V 12g×1 Metal gear with 380mm lead with protection function (Nose wheel steering forward) 7.4V 12g×1 Metal gear with 380mm lead with protection function (Front wheel cover plate forward) 7.4V 12g×2 Metal gear with 380mm lead with protection function (Retarder plate forward) 7.4V 12g×2 Metal gear with 80mm lead with protection function (Rear wheel cover plate forward)
Recommended Power Battery	6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug(required & not included)
Recommended Receiver Battery	2S,7.4V,2200～5200mAh×2,LiPo with XT60 type plug(required & not included)
Ailerons	Yes
Flaps	Yes
Elevator(Horizontal tail)	Yes
Rudder(Vertical tail)	Yes
LED lights system	No (required & not included)
Electromagnetic brake system	No (required & not included)
Retarder plate	Yes
Reinforced gyro	Selective configuration (not included)
Packaging / Size	EPO Inner box + Outer Box /1343×515×450(mm)
CG (Center of Gravity)	120～125mm from the leading edge of the Main Wing
Landing Gears	All metal hydraulic simulation electric retractable landing gear×3 (required & not included)
Battery Charger	LiPo battery charger (required & not included)

PACKAGE INCLUDES:

Fuselage×1 pcs
Left main wing×1 pcs
Right main wing×1 pcs
Nose×1 pcs
Cockpit×1 pcs
Vertical tail×1 pcs
Left Auxiliary oil tank×1 pcs
Right Auxiliary oil tank×1 pcs
Left Horizontal tail ×1 pcs
Right Horizontal tail×1 pcs
Main wing bolt rod 1 L=598mm external diameter 16mm×1 pcs
Main wing bolt rod 2 L=598mm external diameter 10mm×1 pcs
Horizontal Stabilizer bolt rod L=600mm external diameter 6mm×1 pcs
Decals×1 pcs
Accessories Bag 1 ×1 pcs
- Screw (HM3×10mm)×8 pcs (Horizontal tail)
- Screw (HA3×10mm)×8 pcs (Vertical tail)
- Screw (HM4×10mm)×8 pcs (Main wing)
- Screw (HM6×70mm)×8 pcs (Nose + Fuselage)
Accessories Bag 2 ×1 pcs
- 100mm signal line(JR male+JR male)×8 pcs
- Wing antenna ×2 pcs
HME-262 Manual×1 pcs
MFC-2085 Manual×1 pcs

REQUIRES:

8 channel radio system(radio & receiver) (required & not included)
6S,22.2V,5200mAh,45C×2,LiPo with AS150 type plug (required & not included)
2S,7.4V,2200～5200mAh×2,LiPo with XT60 type plug (required & not included)
LiPo battery charger (required & not included)

HSDJETS S-EDF120mm HL-39 PNP Assembly and Pre-Flight Instructions.pdf

Q: What does KIT means?
A:It means aircraft comes without any electronic equipments, such as motor,ESC,servos,remote control,battery,etc. Clients have to buy these equipments themselves.

Q: What does KIT+L means?
A:It's a KIT version but comes with landing gear installed.

Q: What does PNP means?
A: It means the aircraft got equipments already installed and tested, but clients have to buy remote control,receiver,battery and the charger themselves. For example:servos,ESC,power system,landing gear,control system(UBEC included but no power supply), light cables(according to the model of aircrafts).It's a 90% installation.

Q: What does PNP+T means?
A: It's a PNP version with engine(general means turbine) installed and tested. It's a 95% installation.

Q: What does RTF means?
A: It means the aircraft comes with completely equipment installation(including battery supply,charger,remote control and receiver). It's a 100% installation.
